Ordering replacement covers, caps and corners correctly
Order replacement wall protection parts against the installed system code and section geometry. Colour similarity is not enough to prove that a cover or cap will fit.
Selection considerations
Create a handover register with the BULDX code, profile dimensions, finish reference and installed location. Photograph the cross-section where possible, not only the front face. Keep any approved sample label with the register.
Check whether the replacement is a cover, backing, bracket, corner piece or complete assembly. Similar outer covers may use different clips or end details. If the original component is no longer available, compare an alternative technically before ordering quantities. Include a trial fit and inspect the backing for damage so a new cover does not conceal an unresolved fixing problem.
Before you specify or order
- Identify the installed code
- Check clip and cap geometry
- Trial-fit one component
Relevant BULDX catalogue examples
These records illustrate the product types discussed. Compare the full specifications before selecting; listing here does not establish project suitability or make the items interchangeable.
BDX-WG-VA-20025 · Product geometry from the catalogue; a family illustration may be shared by variants. Consult the selected technical documents for dimensions and the approved fixing detail.| Product and code | Selected catalogue fields |
|---|---|
BDX-WG-VA-20025200 × 25 mm Wall GuardCrash Rails |
|
ZHR-50KPCircular Corridor HandrailHandrails |
|
BDX-CG-SS-221022 × 10 mm Stainless-Steel Corner GuardCorner Guards |
|
Common question
Can a matching colour establish compatibility?
No. The fixing and cross-section must match as well as the appearance.
References and scope
Product fields are from the BULDX catalogue. Confirm the current selected drawing, supporting performance documents and approved project detail before ordering. External references, where listed, provide background guidance and do not certify these products.
