How to select hospital corridor handrails

BULDX product guides2 min read

Choose a corridor handrail by its grip geometry, wall projection, fixing arrangement and the protection needed along the route. A combined handrail and wall guard serves a different function from a simple support rail.

AI-generated application context: How to select hospital corridor handrails
APPLICATION ILLUSTRATIONAI-generated application illustration for this guide. Not a completed BULDX project or an installation drawing.

Selection considerations

Start with a corridor survey showing doors, turning areas, equipment routes and changes in wall construction. A rail that looks continuous in elevation may need different anchors where masonry changes to a lightweight partition. Record the backing requirements before the wall closes.

Compare the listed diameter or width with projection from the wall; these dimensions describe different aspects of the section. Ask for end caps, internal corners and external corners as part of the same package. Use the approved accessibility design to establish installation height and clearances rather than selecting them from a photograph.

Before you specify or order

  • Mark wall substrate changes
  • Include returns and corner pieces
  • Confirm grip and clearance in a sample

Relevant BULDX catalogue examples

These records illustrate the product types discussed. Compare the full specifications before selecting; listing here does not establish project suitability or make the items interchangeable.

BULDX catalogue illustration of Circular Corridor Handrail, code ZHR-50KP
CATALOGUE REFERENCEZHR-50KP · Product geometry from the catalogue; a family illustration may be shared by variants. Consult the selected technical documents for dimensions and the approved fixing detail.
Product and codeSelected catalogue fields
ZHR-50KPCircular Corridor HandrailHandrails
Depth
85 mm
Length
4 m
Core
Aluminium
Fixing interval
50-75 cm
ZHR-142DKCombined Handrail & Wall GuardHandrails
Width
142 mm
Depth
80 mm
Length
4 m
Core
Continuous aluminium
ZHR-152DDHeavy-Duty Handrail & Wall GuardHandrails
Width
152 mm
Depth
80 mm
Length
4 m
Core
Continuous aluminium
Fixing interval
50-70 cm
Browse the complete Interior Protection catalogue

Common question

Is a wall guard a handrail?

Not necessarily. A protection rail must also be designed and approved for hand support before it can serve that purpose.

References and scope

Product fields are from the BULDX catalogue. Confirm the current selected drawing, supporting performance documents and approved project detail before ordering. External references, where listed, provide background guidance and do not certify these products.
